Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter

warranty : 1 Year

Brand Name : LONROY

Place of Origin : Hunan, China

Price : $1,000

Voltage : 220 V

MOQ : 1

Weight (KG) : 130

Machine Type : Nanofiber Electrospinning Machine

Contact Now

Products Description
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter

Brief IntroductionThe high-voltage electrospinning machine for nanofibers features a multi-nozzle spinning head, with the number of nozzles being selectable. The support structure is adjustable to achieve the optimal spinning distance and produce non-woven fabrics of varying widths. The high-voltage power supply provides a stable, long-term electric field, with an operating range of 0–30 kV.
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Detailed IntroductionOur high-voltage electrospinning machine utilizes electrospinning technology to produce ultrafine fibers by spraying polymer solutions or melts within a strong electric field. It features a multi-nozzle spinning head with a selectable number of nozzles. The support structure is adjustable to ensure the optimal spinning distance and to produce non-woven fabrics of different widths. The high-voltage power supply delivers a stable, long-term electric field, operating within the 0–30 kV range.Compared to traditional laboratory electrospinning equipment, this system offers superior integration, controllability, and consistency, while delivering high efficiency and a highly integrated design.
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Nanofiber High-Pressure Electrospinning Machine Electrostatic Spinning Tester Spin Fiber Test Equipment Spinnable Polymer Meter
Specification
Technical Parameters
Category
Item
Specification
Power Supply Voltage
AC 220V, 50Hz
Total Power
2.5 kW
High-Voltage Power Supply
Input Voltage
0–30 kV
High-Voltage Power Supply
Maximum Current
0.5 mA
Heating Source
Heating Method
Infrared heating tube
Heating Source
Maximum Temperature
Substrate temperature up to 60°C
Heating Source
Maximum Heating Power
1000 W
Syringe Pump (2 sets)
Syringe Capacity
2.5 mL – 60 mL
Syringe Pump (2 sets)
Flow Rate Range
2.779 μL/min – 72.24 mL/min
Collector
Roller Type
200 mm × φ100, 25, 12, 7, 6.0, 2.0 mm; selectable sizesActuator: DC motor; Mandrel speed: 300–6000 rpm; for electrospinning
Laboratory Nozzle
5-nozzle linear array spinneret
Various nozzle specifications available; selectable inner and outer diameters
